Nachi America

Nachi America 29332EX Spherical Roller Bearings

Nachi America 29332EX Spherical Roller Bearings

Dropship

SKU kpi113-29332EX

MPN : 29332EX

$3,133.75 USD
$3,133.75 USD
Sale Sold out
Shipping calculated at checkout.
No offers currently available
View full details
  • 30-day returns
  • Fast shipping
  • Secure payments
  • Over 300,000 products

Nachi America - 29332EX NACHI Spherical Roller Thrust Bearings utilize barrel shaped rollers to manage extreme thrust loads while rotating with low friction and allowing for up to 2° of angular misalignment. There are two basic designs

  • A conventional “E-Type” design uses a machined brass cages while the “EX-Type” design uses an optimized internal design, larger rollers and a stamped steel cage for higher loads and longer life.

    Additional Information

    Rolling Element Material Steel
    Outer Ring Material Steel
    Limiting Speed - Oil 1400 rpm
    Family Name Spherical Roller Bearings
    Limiting Speed - Grease 850 rpm
    Cage Material Steel
    Temperature Range [Max] 392 °F
    Bore Type Cylindrical Bore
    Bearing Type Thrust
    Inner Ring Material Steel
    ISO Precision Class P0
    Dynamic Load Rating 1040000 N
    Static Load Rating 3500000 N
    Radial Internal Clearance CN/C0
    EAN or UPC 4991893556940
    • CategoryBall Bearings
    Country of originJapan
    Inner diameter160 mm
    ManufactureNachi America
    Mpn29332EX
    Outer diameter270 mm
    SubcategorySpherical Roller Bearings
    Upc4991893556940
    Weight34.14
    Width67 mm
