Nachi America 29434EMY Spherical Roller Bearings

Nachi America 29434EMY Spherical Roller Bearings

Dropship

SKU kpi113-29434EMY

MPN : 29434EMY

$6,174.03 USD
$6,174.03 USD
Sale Sold out
Shipping calculated at checkout.
No offers currently available
View full details
  • 30-day returns
  • Fast shipping
  • Secure payments
  • Over 300,000 products

Nachi America - 29434EMY NACHI Spherical Roller Thrust Bearings utilize barrel shaped rollers to manage extreme thrust loads while rotating with low friction and allowing for up to 2° of angular misalignment. There are two basic designs

  • A conventional “E-Type” design uses a machined brass cages while the “EX-Type” design uses an optimized internal design, larger rollers and a stamped steel cage for higher loads and longer life.

    Additional Information

    Temperature Range [Max] 392 °F
    Family Name Spherical Roller Bearings
    Bore Type Cylindrical Bore
    Outer Ring Material Steel
    Radial Internal Clearance CN/C0
    Static Load Rating 5900000 N
    Rolling Element Material Steel
    Inner Ring Material Steel
    Dynamic Load Rating 1670000 N
    ISO Precision Class P0
    Cage Material Machined High Strength Brass Cage
    Bearing Type Thrust
    Limiting Speed - Oil 950 rpm
    EAN or UPC 4991893558944
    • CategoryBall Bearings
    Country of originJapan
    Inner diameter170 mm
    ManufactureNachi America
    Mpn29434EMY
    Outer diameter340 mm
    SubcategorySpherical Roller Bearings
    Upc4991893558944
    Weight97.00
    Width103 mm
