Nachi America - 51101 Thrust Ball Bearings are made as single-direction and double-direction bearings. Single-direction Thrust Ball Bearings can sustain an axial load in only one direction, whereas Double-direction Thrust Ball Bearings can sustain bi-directional thrust load. Both types of Thrust Ball Bearings cannot sustain a radial load.
Features
Standard steel cage
Additional Information
Dynamic Load Rating 10300 N
Bearing Type Thrust
ISO Precision Class P0
Limiting Speed - Grease 6500 rpm
Limiting Speed - Oil 9800 rpm
Cage Material Steel
Width 9 mm
Rolling Element Material Steel
Seals or Shields No
Ball Material Steel
Outer Ring Material Steel
Bore Type Cylindrical Bore
Temperature Range [Max] 248 °F
Static Load Rating [Max] 15400 N
Inner Ring Material Steel
EAN or UPC 4991893593914
CategoryBall Bearings
Country of originJapan
Inner diameter12 mm
ManufactureNachi America
Mpn51101
Outer diameter26 mm
SubcategoryThrust Ball Bearing
Upc4991893593914
Weight0.05
Width9 mm
