category:
Ball Bearings
country_of_origin:
Japan
inner_diameter:
17 mm
manufacture:
Nachi America
mpn:
51103G
outer_diameter:
30 mm
subcategory:
Thrust Ball Bearing
upc:
4991893594065
weight:
0.06
width:
9 mm
Product Description
Thrust Ball Bearings are made as single-direction and double-direction bearings. Single-direction Thrust Ball Bearings can sustain an axial load in only one direction, whereas Double-direction Thrust Ball Bearings can sustain bi-directional thrust load. Both types of Thrust Ball Bearings cannot sustain a radial load.
Features
(G) = PA66 Polyamide cage
Additional Information
Inner Ring Material Steel
Width 9 mm
Bearing Type Thrust
Rolling Element Material Steel
Outer Ring Material Steel
Dynamic Load Rating 10800 N
Ball Material Steel
Bore Type Cylindrical Bore
Temperature Range [Max] 248 °F
Seals or Shields No
Static Load Rating [Max] 18200 N
ISO Precision Class P0
Limiting Speed - Grease 6000 rpm
Cage Material Polyamide Resin
Limiting Speed - Oil 9100 rpm
EAN or UPC 4991893594065
