Nachi America - 51203G Thrust Ball Bearings are made as single-direction and double-direction bearings. Single-direction Thrust Ball Bearings can sustain an axial load in only one direction, whereas Double-direction Thrust Ball Bearings can sustain bi-directional thrust load. Both types of Thrust Ball Bearings cannot sustain a radial load.
Features
(G) = PA66 Polyamide cage
Additional Information
Rolling Element Material Steel
Outer Ring Material Steel
Limiting Speed - Oil 7300 rpm
Dynamic Load Rating 17100 N
Seals or Shields No
Bore Type Cylindrical Bore
Temperature Range [Max] 248 °F
ISO Precision Class P0
Ball Material Steel
Cage Material Polyamide Resin
Bearing Type Thrust
Inner Ring Material Steel
Limiting Speed - Grease 4800 rpm
Static Load Rating [Max] 27300 N
Width 12 mm
EAN or UPC 4991893595871
CategoryBall Bearings
Country of originJapan
Inner diameter17 mm
ManufactureNachi America
Mpn51203G
Outer diameter35 mm
SubcategoryThrust Ball Bearing
Upc4991893595871
Weight0.12
Width12 mm
