category:
Ball Bearings
country_of_origin:
Japan
inner_diameter:
12 mm
manufacture:
Nachi America
mpn:
5201NR
outer_diameter:
32 mm
subcategory:
Angular Contact Ball Bearing
upc:
4991893598353
weight:
0.13
width:
15.9 mm
Product Description
Double-Row Angular Contact Ball Bearings have a thinner width than 2 stacked Deep-Groove bearings & can sustain combined loads of simultaneously acting radial and axial loads because they have a contact angle (α). The contact angle is defined as the angle between the line joining the points of contact between the ball and the raceways in the radial plane.
Features
(-2NS) = 2 NBR Contact Seals, (ZZ) = 2 Shields, (NR) = Snap Ring & Snap Ring Groove on OD, (C3) = C3 Radial Clearance
Additional Information
Limiting Speed - Grease 16000 rpm
Bore Type Cylindrical Bore
Inner Ring Material Steel
Bearing Type Angular Contact
Temperature Range [Max] 248 °F
Contact Angle 20°
Cage Material Steel
Outer Ring Material Steel
Width 15.9 mm
ISO Precision Class P0
Dynamic Load Rating 10700 N
Static Load Rating [Max] 5950 N
Limiting Speed - Oil 22000 rpm
Seals or Shields No
Rolling Element Material Steel
Ball Material Steel
Snap Ring Yes
Rows of Balls Double
EAN or UPC 4991893598353
