category:
Ball Bearings
country_of_origin:
Japan
inner_diameter:
15 mm
manufacture:
Nachi America
mpn:
5202NR
outer_diameter:
35 mm
subcategory:
Double Row Angular Contact Ball Bearing
upc:
4991893856699
weight:
0.15
width:
15.9 mm
Product Description
Double-Row Angular Contact Ball Bearings have a thinner width than 2 stacked Deep-Groove bearings & can sustain combined loads of simultaneously acting radial and axial loads because they have a contact angle (α). The contact angle is defined as the angle between the line joining the points of contact between the ball and the raceways in the radial plane.
Features
(-2NS) = 2 NBR Contact Seals, (ZZ) = 2 Shields, (NR) = Snap Ring & Snap Ring Groove on OD, (C3) = C3 Radial Clearance
Additional Information
ISO Precision Class P0
Limiting Speed - Oil 19000 rpm
Inner Ring Material Steel
Contact Angle 20°
Seals or Shields No
Bearing Type Angular Contact
Rows of Balls Double
Temperature Range [Max] 248 °F
Snap Ring Yes
Dynamic Load Rating 11900 N
Width 15.9 mm
Cage Material Steel
Outer Ring Material Steel
Limiting Speed - Grease 14000 rpm
Bore Type Cylindrical Bore
Static Load Rating [Max] 7200 N
Ball Material Steel
Rolling Element Material Steel
EAN or UPC 4991893856699
