category:
Ball Bearings
country_of_origin:
Japan
inner_diameter:
70 mm
manufacture:
Nachi America
mpn:
6014-2NSENR
outer_diameter:
110 mm
subcategory:
Deep Groove Ball Bearing
upc:
4991893651959
weight:
1.34
width:
20 mm
Product Description
Because of their versatility, Single-row, Deep-groove Ball Bearings are the most popular of all the ball bearing types. NACHI Deep-groove Ball Bearings are available in a wide range of series defined by the JIS (ISO) standard dimension plan and are also made to meet specialized dimension and configuration requirements.
Features
NACHI Deep-Groove Ball Bearings are availible open, sealed, or shielded. (-2NSE9) = 2 High Performance NBR Contact Seals, (-2NKE9) = 2 High Performance NBR Non-Contact Seals, (ZZE) = 2 Heavy Duty Shields, (-2NSL) = 2 Large Size NBR Contact Seals, (ZZ) = 2 Large Size Shields, (MY) = Brass Cage
Additional Information
Seals or Shields 2 Contact Seals
Limiting Speed - Grease 3600 rpm
Bearing Type Deep Groove
Temperature Range [Max] 248 °F
Width 20 mm
Ball Material Steel
Outer Ring Material Steel
Bore Type Cylindrical Bore
Inner Ring Material Steel
Grease Fill Chevron SRI#2
Static Load Rating [Max] 31000 N
Rolling Element Material Steel
Cage Material Steel
Dynamic Load Rating 38000 N
Snap Ring Yes
ISO Precision Class P0
EAN or UPC 4991893651959
