category:
Ball Bearings
country_of_origin:
Japan
inner_diameter:
65 mm
manufacture:
Nachi America
mpn:
6213NR
outer_diameter:
120 mm
subcategory:
Deep Groove Ball Bearing
upc:
4991893729313
weight:
2.18
width:
23 mm
Product Description
Because of their versatility, Single-row, Deep-groove Ball Bearings are the most popular of all the ball bearing types. NACHI Deep-groove Ball Bearings are available in a wide range of series defined by the JIS (ISO) standard dimension plan and are also made to meet specialized dimension and configuration requirements.
Features
NACHI Deep-Groove Ball Bearings are availible open, sealed, or shielded. (-2NSE9) = 2 High Performance NBR Contact Seals, (-2NKE9) = 2 High Performance NBR Non-Contact Seals, (ZZE) = 2 Heavy Duty Shields, (-2NSL) = 2 Large Size NBR Contact Seals, (ZZ) = 2 Large Size Shields, (MY) = Brass Cage
Additional Information
Ball Material Steel
Static Load Rating [Max] 40000 N
Dynamic Load Rating 57000 N
Limiting Speed - Oil 6500 rpm
Outer Ring Material Steel
Seals or Shields No
ISO Precision Class P0
Snap Ring Yes
Cage Material Steel
Width 23 mm
Bore Type Cylindrical Bore
Bearing Type Deep Groove
Inner Ring Material Steel
Limiting Speed - Grease 5500 rpm
Rolling Element Material Steel
Temperature Range [Max] 248 °F
EAN or UPC 4991893729313
