category:
Ball Bearings
country_of_origin:
Japan
inner_diameter:
190 mm
manufacture:
Nachi America
mpn:
6338MYC3
outer_diameter:
700 mm
subcategory:
Deep Groove Ball Bearing
upc:
4991893857856
weight:
106.26
width:
78 mm
Product Description
Because of their versatility, Single-row, Deep-groove Ball Bearings are the most popular of all the ball bearing types. NACHI Deep-groove Ball Bearings are available in a wide range of series defined by the JIS (ISO) standard dimension plan and are also made to meet specialized dimension and configuration requirements.
Features
NACHI Deep-Groove Ball Bearings are availible open, sealed, or shielded. (-2NSE9) = 2 High Performance NBR Contact Seals, (-2NKE9) = 2 High Performance NBR Non-Contact Seals, (ZZE) = 2 Heavy Duty Shields, (-2NSL) = 2 Large Size NBR Contact Seals, (ZZ) = 2 Large Size Shields, (MY) = Brass Cage
Additional Information
Limiting Speed - Oil 1900 rpm
Temperature Range [Max] 248 °F
Dynamic Load Rating 355000 N
Cage Material Machined High Strength Brass Cage
Seals or Shields No
Bearing Type Deep Groove
Rolling Element Material Steel
Static Load Rating [Max] 415000 N
Ball Material Steel
Bore Type Cylindrical Bore
ISO Precision Class P0
Inner Ring Material Steel
Width 78 mm
Outer Ring Material Steel
Snap Ring No
Limiting Speed - Grease 1600 rpm
EAN or UPC 4991893857856
