Nachi America N313MC3 N300 Series Cylindrical Roller Bearing, N313Mc3Bnls

Nachi America N313MC3 N300 Series Cylindrical Roller Bearing, N313Mc3Bnls

Dropship

SKU SKU:kpi113-N313MC3

Regular price $306.48 USD
Regular price Sale price $306.48 USD
Sale Sold out
Shipping calculated at checkout.
View full details
  • 30-day returns
  • Fast shipping
  • Secure payments
  • Over 300,000 products
category: Cylindrical & Needle Bearings
country_of_origin: Japan
inner_diameter: 65 mm
manufacture: Nachi America
mpn: N313MC3
outer_diameter: 140 mm
subcategory: Cylindrical Roller Bearing - Single Row
upc: 4991893859614
weight: 4.90
width: 33 mm

Product Description

Cylindrical Roller Bearings utilize a modified cylindrical roller that provides line contact with the inner and outer ring raceways. They are suitable for high speeds and have a high radial load capacity. The rollers are guided by ribs on either the inner or outer rings. Depending upon the configuration, the bearings may or may not be able to accept any axial loading. The inner and outer rings are separable which may aid in the assembly/disassembly of components. The ‘N’ Type bearings only have shoulders on both sides of the inner ring. This allows the shaft to move axially within the outer ring. This is important for thermal expansion. Stamped steel or machined brass (MY) cages are generally used. These bearings are most commonly used in gearboxes, rolling mills, crushers and pulverizers.

Features

Separable components simplify mounting,removal, and can be interchangable in configuration. Long life. Heavy radial load capacity. Not suitable for thrust loads. Accommodates axial expansion and contraction.

Additional Information

Cage Material Machined High Strength Brass Cage
Outer Ring Material Steel
ISO Precision Class P0
Static Load Rating 139000 N
Radial Internal Clearance C3
Snap Ring No Snap Ring
Bore Type Cylindrical Bore
Rolling Element Material Steel
Inner Ring Material Steel
Temperature Range [Max] 248 °F
Rows of Balls Single
Seals or Shields No
Dynamic Load Rating 135000 N
Limiting Speed - Grease 4500 rpm
Limiting Speed - Oil 5300 rpm
EAN or UPC 4991893859614
