category:
Controls Sensors
manufacturer:
Siemens
mpn:
536-778
Outside Air Temperature Sensor, 100K Ohm Thermistor
This outdoor air sensor provides input for cost-effective, accurate temperature sensing via an 18 AWG twisted, shielded cable pair. The sensor resistance varies proportionally to the temperature being measured and has a 100,000 Ohm reference resistance at 77 degrees Fahrenheit. This sensor allows through-the-wall mounting for outside air temperature measurements and has a temperature range of 0 to 120 degrees Fahrenheit; uses metal housing.
Additional Information
Measuring range, temperature-18…49 °C
Sensing element100K ohm Thermistor
Analog outputs100k Ohm Thermistor
Measuring range-40 to 150 °F
Measurement accuracy+/-0.50°F @ 77 °F
Material, housingMetal
Sensing elementNTC 100k
