manufacturer:
Siemens
mpn:
GLB346.1U
Product Description
Siemens - GLB346.1U Damper Actuator | Non-Spring Return | 120 to 230 VAC | On/Off/Floating Point | 88 lb-in | SWDamper Actuator 88 lb-in 2-position/floating control signal, non-spring return, built in auxiliary switches, supply voltage 100 to 240 VAC, for use in constant or variable air volume installations for control of HVAC dampers.
Additional Information
Control or Fire/Smoke TypeControl Damper
Torque88 lb-in
Positioning time50 Hz:150 s, 60 Hz:125 s
Position feedbackNo
Power consumption5.8 VA, 1.9 W
Ambient humidity, operation95 % r.h.
Angular rotation90°
Operating voltage100…240 V24 V#AC
Frequency50/60 Hz
Auxiliary switch2
Cable length3 ft
Dimensions (W x H x D)2.7 x 6.6 x 2.4 in
Material, housingNEMA 2, IP54 per EN60529, durable plastic
Degree of protectionIP60
