manufacturer:
Siemens
mpn:
GPC326.1U
Product Description
Siemens - GPC326.1U Damper Actuator | Spring Return | 120 to 230 VAC | On/Off | 35 lb-in | SWDamper actuator spring return, 35 lb-in 2-position control. 120 to 230 VAC with fixed dual built in auxiliary switches and plenum rated. For use on small control dampers
OpenAir GPC Series Electric Damper Actuator, spring return, 35 lb-in. For use on economizer dampers and small control dampers
Additional Information
Actuator TypeSpring return
Actuation StyleRotary
Control or Fire/Smoke TypeControl Damper
Plenum or Standard RatingStandard
Torque35 lb-in
Fail SafeYes
Control Signal2-position
Positioning timeRuntime for 90° 60 s
Position feedbackNo
Power consumptionRunning: 4.6 VA (2.4 W), Holding: 3.5 VA (1.7 W)
Ambient temperature, operation-25 to 130 °F, -32 to 55 °C
Angular rotation90°
Operating voltage120-230 VAC
Supply Voltage120 to 230 VAC
Frequency50/60 Hz
Auxiliary SwitchYes
Auxiliary switch2
Cable length3 ft
Dimensions (W x H x D)2.83 x 5.61 x 2.48 in
Material, housingNEMA 1, Plenum rated rugged plastic
