manufacturer:
Siemens
mpn:
GQD221.1U
Product Description
Siemens - GQD221.1U Damper Actuator | Spring Return | 120 VAC | On/Off | 20 lb-inOpenAir™ GQD Series Electric Damper Actuator, rotary, spring return, 20 lb-in (2 Nm), 120 Vac, 2-position control, 30 sec run time
Additional Information
Control or Fire/Smoke TypeControl Damper
Torque20 lb-in
Positioning timeOpen:30 s, Close:15 s
Position feedbackNo
Power consumptionRunning: 10 VA, Holding: 7 VA
Ambient humidity, operation95 % r.h.
Angular rotation90°
Operating voltage102…138 VAC
Frequency50/60 Hz
Cable length3 ft
Dimensions (W x H x D)2.72 x 5.5 x 2.47 in
Material, housingNEMA 1, plenum-rated rugged plastic, IP40
Degree of protectionIP40
