manufacturer:
Siemens
mpn:
GQD226.1U
Product Description
Siemens - GQD226.1U Damper Actuator | Spring Return | 120 VAC | On/Off | 20 lb-in | SWOpenAir™ GQD Series Electric Damper Actuator, rotary, spring return, 20 lb-in (2 Nm), 120 Vac, 2-position control, 30 sec run time, auxiliary switches
Additional Information
Control or Fire/Smoke TypeControl Damper
Torque20 lb-in
Positioning timeOpen:30 s, Close:15 s
Position feedbackNo
Power consumptionRunning: 10 VA, Holding: 7 VA
Ambient humidity, operation95 % r.h.
Angular rotation90°
Operating voltage102…138 V24 V#AC
Frequency50/60 Hz
Auxiliary switch2
Cable length3 ft
Dimensions (W x H x D)2.72 x 5.5 x 2.47 in
Material, housingNEMA 1, plenum-rated rugged plastic, IP40
Degree of protectionIP40
