manufacturer:
Siemens
mpn:
GSD161.1P
Product Description
Siemens - GSD161.1P Damper Actuator | Non-Spring Return | 24 VAC/DC | 0-10Vdc / 2-10Vdc | 20 lb-inDamper Actuator 20 lb-in 0(2) to 10 modulating control signal, non-spring return plenum rated for low torque VAV applications and small dampers.
Additional Information
Actuator TypeNon-spring return
Actuation StyleRotary
Control or Fire/Smoke TypeControl Damper
Plenum or Standard RatingPlenum
Torque20 lb-in
Fail SafeNo
Control Signal0...10Vdc / 2...10Vdc
Positioning timeRuntime for 90° 30 s
Position feedbackYes
Power consumptionRunning: 2.4 VA (1.4 W), Holding: 1.2 VA (0.7 W)
Ambient temperature, operation-25 to 130 °F, -32 to 55 °C
Operating voltage24 VAC, 24 VDC
Supply Voltage24 VAC/DC
Frequency50/60 Hz
Auxiliary SwitchNo
Cable length3 ft
Dimensions (W x H x D)2.83 x 5.86 x 2.45 in
Material, housingIP54 enclosure, Plenum rated rugged plastic
