manufacturer:
Siemens
mpn:
GSD341.1U
Product Description
Siemens - GSD341.1U Damper Actuator | Non-Spring Return | 120 to 230 VAC | On/Off/Floating Point | 20 lb-inDamper Actuator 20 lb-in 2-position/floating control, non-spring return, supply voltage 100 to 240 VAC. For low torque VAV applications and small dampers.
Additional Information
Actuator TypeNon-spring return
Actuation StyleRotary
Control or Fire/Smoke TypeControl Damper
Plenum or Standard RatingStandard
Torque20 lb-in
Fail SafeNo
Control Signal2-position , Floating control
Positioning timeRuntime for 90° 30 s
Position feedbackNo
Power consumptionRunning: 4.5 VA (1.8 W), Holding: 2.4 VA (0.9 W)
Ambient temperature, operation-25 to 130 °F, -32 to 55 °C
Operating voltage120-230 VAC
Supply Voltage120 to 230 VAC
Frequency50/60 Hz
Auxiliary SwitchNo
Cable length3 ft
Dimensions (W x H x D)2.83 x 5.86 x 2.45 in
Material, housingIP54 enclosure, Plenum rated rugged plastic
