manufacturer:
Siemens
mpn:
SFP71U
Product Description
Siemens - SFP71U Zone Valve Electronic Actuator, 24 Vac, 2-Position, NO, SR.
SF Series electronic zone valve actuator, 24 Vac, normally open, 2-position, with spring return. Works with Siemens 599 Series zone valves with 1/10-inch (2.5 mm) stroke. UL listed for plenum installations, manual override.
Additional Information
Actuator TypeElectronic
Control or Fire/Smoke TypeControl Damper
Force105 N
Fail SafeYes
Control Signal2-position
Positioning time10 s
Power consumption9.8 VA
Mounting positionNEMA 1 (interior only)
Ambient temperature, operation1…50 °C
Ambient humidity, operation0% to 90% rh (non-condensing)
Operating voltage120 VAC
Supply Voltage24 VAC
Stroke2.5 mm
Cable length2.5 m
Dimensions (W x H x D)4.4 x 3.4 x 2.3 in
Degree of protectionIP54
