manufacturer:
Siemens
mpn:
SKD82.50U
Product Description
Siemens - SKD82.50U Flowrite Electro-Hydraulic Actuator, float, NSR, 3/4" Stroke
The Flowrite SKD Valve Actuator is used with Flowrite and other standard valves with a 3/4-inch stroke. This electronic valve actuator requires a 24 Vac supply to provide floating control of the valve. Normally closed and 3-way upper port nominal force is 225 lb-in (1000N); normally open and 3-way bypass port is 258 lb-in (1150N). Other features of this valve actuator include automatic stroke calibration, manual override, die-cast aluminum housing, and non-spring return functionality.
Additional Information
Ambient temperature, operation-15…50 °C
Degree of protectionIP54
Dimensions (W x H x D)11.81 x 5 x 6.65 in
Medium temperature-25…150 °C; 5…130 ºF
Mounting positionNEMA 1 (interior only), Upright
Positioning time120 s
Spring return functionNon-spring return functionality
Stroke20 mm
Operating voltage19.2…28.2 V24 V#AC
Power consumption9 VA
Positioning force1000 N
Positioning signal3-position
