Product details
manufacturer: Siemens
mpn: SSC81U
MT Series Actuator, 24 Vac, floating control, NSR, 300N.
Powermite MT Series actuator, 24 Vac, floating control, non-spring return. Works with MT Series valves with 7/32-inch (5.5mm) stroke. UL listed for plenum installations, manual override with visual position indication. Provides 65 lb. (300 N) nominal force.
Additional Information
Fail SafeNo
Spring return functionNon-spring return functionality
Ambient temperature, operation5…50 °C
Ambient humidity, operation90 % r.h.
Operating voltage24 VAC/DC
Supply Voltage24 VAC
Degree of protectionIP40
