category:
Lifting & Moving Equipments
country_of_origin:
USA
handle_type:
Hand Wheel
height:
71.6"
lifting_capacity:
250 lbs.
load_capacity:
1/8 Ton
manufacturer:
Sky Hook
mpn:
A9570
product_type:
Economy Articulating Sky Hook With Mobile Cart Base - 36" Reach
weight:
241 lbs.
Product Description
Features- Lever operated friction brake style while allowing safe and controlled lifting up to 500 lbs.
- Bolt down adapters available for easy mounting to any suitable flat surface.
- Uses one hand operation that does the work of four people.
- Controlled lowering of the load by pulling back on the friction brake lever while applying a slight amount of pressure to the hand wheel with the palm of your hand.
- Operates in tight working conditions.
- Easily detach and carry to different locations perfect for any work space.
- Prevents lifting injuries.
- No maintenance needed.
- ASME and OSHA standards tested.
- CSA and CE certified.
Additional Information
Weight241 lbs.
TypeEconomy Articulating Sky Hook With Mobile Cart Base - 36" Reach
Load Capacity1/8 Ton
Lift Speed1.5" Per Handwheel Revolution
Maximum Lift Distance100"
MaterialWire Rope
Handle TypeHand Wheel
Overall Height71.6"
Lifting Capacity250 lbs.
048_Notes Data_WebCounter Weight Required, Sold Separately. ·630 lb. counter weight kit Model #CW-630-KIT for 500 lb. load capacity is available. ·Individual counter weight Model #CW-42LB for loads less than 500 lbs. is available.
Base TypeMobile Cart Base
BrakeLoadLock Clutch Brake
Finish CoatingPowder Coated
Pivots360°
Prop. 65Yes
Reach36"
Country of OriginUNITED STATES OF AMERICA
