country_of_origin:
TW
manufacturer:
US Motors
mpn:
EH514
Features
- Three Phase Pool & Spa
- Square & C-Face Flange
- C-Flange Keyed & Threaded Shaft Full Service Factor Full Rated
Additional Information
PHASETYPE:3_POLYPHASE
MOTOR ENCLOSURE:ODP
HORSEPOWER:1
KILOWATTS:0.8
POLES:2
NUMBER SPEEDS:1
RPM:3450
RPM 2:2850
HERTZ:60
HERTZ 2:50
VOLTS PRIMARY:208-230/460 V
VOLTS :208
VOLTS 2:230
VOLTS 3:460
STATOR DIAMETER:6.3
STACK:1.375
MOUNTING:C-FACE
MOTOR TYPE:FHP
OPPOSITE END BEARING:BALL
SHAFT END BEARING:BALL
AMBIENT:50
ROTATION:CCW DRIVE END REV
SERVICE FACTOR:1.4
SHIPPING WEIGHT:24
THERMAL PROTECTION:NONE
BREAKDOWN TORQUE:110
BREAKDOWN TORQUE UOM:OZFT
LOCKED ROTOR TORQUE:63.21
LOCKED ROTOR TORQUE UOM:OZFT
INSULATION CLASS:B
KVA CODE LETTER:L
LOCKED ROTOR AMPS:22.02
SERVICE FACTOR AMPS PRIMARY:4.4-4.2/2.1
