country_of_origin:
TW
manufacturer:
US Motors
mpn:
FD13CM2PCR
Product Description
US Motors - FD13CM2PCR
Features- Special Application Farm
- Totally Enclosed Fan Cooled (TEFC)
- Agri Duty High Torque
- Single Phase Capacitor Start
- C-Face Footless
Additional Information
PHASETYPE:1_CAPACITOR START
MOTOR ENCLOSURE:TEFC
HORSEPOWER:.33
KILOWATTS:0.3
POLES:4
NUMBER SPEEDS:1
RPM:1725
HERTZ:60
VOLTS PRIMARY:115/230 V
VOLTS :115
VOLTS 2:230
FRME :56
SHAFT CODE:C
STATOR DIAMETER:6.3
STACK:1.25
MOUNTING:C-FACE
MOTOR TYPE:FHP
OPPOSITE END BEARING:6203
SHAFT END BEARING:6203
AMBIENT:40
ROTATION:REVERSIBLE
SERVICE FACTOR:1.15
STARTCAPMFD:198.45
SHIPPING WEIGHT:21
THERMAL PROTECTION:MANUAL RESET
BREAKDOWN TORQUE:54.95
BREAKDOWN TORQUE UOM:OZFT
LOCKED ROTOR TORQUE:73.41
LOCKED ROTOR TORQUE UOM:OZFT
INSULATION CLASS:B
KVA CODE LETTER:L
LOCKED ROTOR AMPS:28.3
NEMA NOMINAL EFFICIENCY:59.5
FULL LOAD AMPS PRIMARY:6.6/3.3
SERVICE FACTOR AMPS PRIMARY:6.8/3.4
