country_of_origin:
TW
manufacturer:
US Motors
mpn:
H7T3BC
Features
- Definite Purpose ACCU-SERIES
- TEFC & TENV
- HOSTILE DUTY Inverter Duty
- 20:1 (3-60 Hz) Speed Range Constant Torque
Additional Information
PHASETYPE:3_PHASE
MOTOR ENCLOSURE:TEFC
HORSEPOWER:7.5
KILOWATTS:5.6
POLES:6
NUMBER SPEEDS:1
RPM:1185
RPM 2:1185
HERTZ:60
VOLTS PRIMARY:230/460
VOLTS :460
VOLTS 2:230
FRME :254
SHAFT CODE:TC
MOUNTING:HORZ-FOOTED
ASSEMBLY POSITION:F1
MOTOR TYPE:CTI
OPPOSITE END BEARING:6309-2Z-J/C3
SHAFT END BEARING:6310-J/C3
AMBIENT:40
ROTATION:DUAL
SERVICE FACTOR:1
STARTCAPMFD:N\A
SHIPPING WEIGHT:300
BREAKDOWN TORQUE:359
BREAKDOWN TORQUE UOM:PERCENT OF FLT
LOCKED ROTOR TORQUE:257
LOCKED ROTOR TORQUE UOM:PERCENT OF FLT
INSULATION CLASS:H
KVA CODE LETTER:J
LOCKED ROTOR AMPS:75.2
NEMA NOMINAL EFFICIENCY:91
FULL LOAD AMPS PRIMARY:20.2/10.1
