Product Description
US Motors - SV34SA4D
Features- Three Phase
- Refrigeration Duty
- Totally Enclosed Air Over (TEAO)
- 60/50 Hz Cycle
- Band and Rigid Base
Additional Information
PHASETYPE:3_POLYPHASE
MOTOR ENCLOSURE:TEAO
HORSEPOWER:.75
KILOWATTS:0.6
POLES:8
NUMBER SPEEDS:1
RPM:850
RPM 2:700
HERTZ:60
HERTZ 2:50
VOLTS PRIMARY:208-230/460 190/380 V
VOLTS :208
VOLTS 2:230
VOLTS 3:460
VOLTS 4:190
VOLTS 5:380
FRME :56
STATOR DIAMETER:6.3
STACK:4.5
MOUNTING:RIGID BASE
MOTOR TYPE:FHP
OPPOSITE END BEARING:BALL
SHAFT END BEARING:BALL
AMBIENT:40
ROTATION:REVERSIBLE
SERVICE FACTOR:1.15
SHIPPING WEIGHT:32
THERMAL PROTECTION:AUTOMATIC RESET
BREAKDOWN TORQUE:280.3
BREAKDOWN TORQUE UOM:OZFT
LOCKED ROTOR TORQUE:185.3
LOCKED ROTOR TORQUE UOM:OZFT
INSULATION CLASS:F
KVA CODE LETTER:H
LOCKED ROTOR AMPS:15.21
NEMA NOMINAL EFFICIENCY:76.2
FULL LOAD AMPS PRIMARY:4.5/2.3
SERVICE FACTOR AMPS PRIMARY:4.7/2.4
