Data Sheet Product Description
Vestil - HDC-905-IDC/230V
Drum Crusher, Automatic Reset Yes, Chamber Depth 25 in, Chamber Height 35.75 in, Chamber Width 25 in, Crushing Force 38,000 psi, Cycle Time 25 sec, For Drum Capacity 55 gal, For Drum Material Metal, For Maximum Drum Diameter 6 in, For Maximum Drum Height 35 3/4 in, Motor Enclosure Totally Enclosed, Motor Type AC Motor, Operating Voltage 230V AC, Overall Depth 38 in, Overall Height 91 in, Overall Width 37 in, Phase Three, Power Source Hydraulic, Assembly Fully Assembled
Additional Information
Overall Length (In.)40 in
Overall Width (In.)35 in
Chamber Height (In.)37
Chamber Length (In.)25
Overall Height (In.)98 in
Chamber Width (In.)25
Overall Height91 in
Overall Width37 in
For Maximum Drum Height35 3/4 in
Chamber Depth25 in
For Maximum Drum Diameter6 in
Overall Depth38 in
Manufacturer Warranty Length1 yr Limited
Chamber Width25 in
Chamber Height35.75 in
Item Drum Crusher
Standards JIC, OSHA
Features (2) Pressure Switches (High Pressure for Drum Crushing Low Pressure for Compacting Contents Inside a Drum), 24V Control Circuit, Cruch/Compact Selector Switch, Cycle Start Button, Door Interlock Switch, Drum Head Piercer to Release Internal Drum Pressure, On/Off Switch, Positive Drum Positioning
Maximum Motor Horsepower 6 1/2 hp
Frequency 60 Hz
Motor Type AC Motor
Power Source Hydraulic
For Drum Capacity 55 gal
Automatic Reset Yes
Cycle Time 25 sec
Housing Color Blue
Crushing Force 38,000 psi
For Drum Material Metal
Operating Voltage 230V AC
Assembly Fully Assembled
Crushing Plate Weight 75 lb
Oil Reservoir Capacity 18 gal
Phase Three
Drip Pan Capacity 1 gal
Motor Enclosure Totally Enclosed
Housing Material Steel
