category:
WELDING SUPPLIES
manufacturer:
Nasco
mpn:
341-0781-1445
subcategory:
GAS CUTTING & WELDING
Product Description
Nasco - 341-0781-1445
| Lead Time | 1-2 Weeks |
|---|---|
| Manufacturer Part Number | 0781-1445 |
| GTIN | 716352082501 |
| Family | Victor SR 4 High Pressure Single Stage Piston Regulators |
| Manufacturer | Thermadyne |
| Hazmat | N |
| Testing and Approvals | UL Listed; Conforms to CGA E-4 |
| Country of Origin | US |
| Features | High pressure Dead-end testing May be panel mounted Single stage design Piston type actuation All SR 4 series regulators have a swaged lock type stainless steel outlet fitting Cartridge type seat assembly with PCTFE seat Delrin cap bushing for smooth adjustments External adjustable relief valves on F and G range models Hydrogen models have ventable relief valves |
| Body Material | Machined Brass |
| Depth [Nom] | 6 1/4 in |
| Filter Material | Bronze; Sintered |
| Gas Type | Oxygen |
| Height [Nom] | 6 1/2 in |
| Inlet Connection | CGA 540 |
| Inlet Pressure [Max] | 3,000 psig |
| Outlet Pressure [Max] | 3,000 psig |
| Outlet Pressure [Min] | 200 psig |
| Outlet Size | 1/4 in |
| Outlet Type | Swagelok |
| Width [Nom] | 6 in |
| Wt. | 4 lb |
