category:
Farm Duty
manufacturer:
Weg
mpn:
00218ES1RFD184T-S
weight:
90
Catalog Number:00218ES1RFD184T-S
StandardNEMA MG-1
Frequency60 Hz
Voltage115/230 V
Number of poles4
Degree of ProtectionIP55
Synchronous speed1800 rpm
Output rating2 HP
MountingF-1
FlangeWithout
Terminal box¹Left position
EnclosureIC411 - TEFC
Frame182/4T
Output2 HP (1.5 kW)
Rated speed1770 RPM
Slip0.0167
Rated voltage115/230 V
Rated current19.9/9.96 A
L. R. Amperes205/103 A
LRC10.3x(Code N)
No load current11.8/5.90 A
Rated torque5.93 ft.lb
Locked rotor torque4.09
Breakdown torque3.9
Locked rotor time10s (cold) 6s (hot)
Moment of inertia (J)0.3246 sq.ft.lb
Insulation ClassF
Service factor1.15
Temperature rise80 K
Duty CycleCont.(S1)
Starting MethodDirect On Line
Ambient temperature-20°C to +40°C
Altitude1000 m.a.s.l.
Rotation¹Both (CW and CCW)
Noise level²59.0 dB(A)
Frame MaterialRolled Steel
Impregnation MethodDip and Bake Polyester
Main terminal box hole1.377"
Terminal BlockWithout
DrainRubber, automatic
Shaft MaterialSAE 1040/45 Carbon Steel
PaintingRAL 3003 207N (ISO 12944 - C2)
Grounding LugsSingle
Fan Cover materialSteel
Tropicalized PaintingWithout
Fan materialPlastic
Bearing capNo-Without Bearing Cap
Balancing Method1/2 Key
Drip CoverWithout
Overload protector (phenolic)Manual
Bolt MaterialCarbon Steel
Resilient BaseWithout
