category:
General Purpose
manufacturer:
Weg
mpn:
00736ES1B213T-W22
subcategory:
Tefc Cast Iron
weight:
159
Catalog Number:0736ES1B213T-W22
StandardNEMA MG-1
Frequency60 Hz
Voltage115/208-230 V
Number of poles2
Degree of ProtectionIP55
Synchronous speed3600 RPM
Output rating7.5 HP
MountingF-1
FlangeWithout
Terminal box¹Left position
EnclosureIC411 - TEFC
Frame213/5T
Output7.5 HP (5.5 kW)
Rated speed3520 RPM
Slip0.0222
Rated voltage115/208-230 V
Rated current61.4/33.9-30.7 A
L. R. Amperes497/275-249 A
LRC8.1x(Code J)
No load current20.8/13.3-10.4 A
Rated torque11.2 ft.lb
Locked rotor torque2.1
Breakdown torque3.1
Locked rotor time12s (cold) 7s (hot)
Moment of inertia (J)0.4865 sq.ft.lb
Insulation ClassF
Service factor1.15
Temperature rise105 K
Duty CycleCont.(S1)
Starting MethodDirect On Line
Ambient temperature-20°C to +40°C
Altitude1000 m.a.s.l.
Rotation¹Both (CW and CCW)
Frame MaterialCast Iron
Impregnation MethodDip and Bake Polyester
Main terminal box holeNPT 1"
Terminal BlockWithout
DrainRubber, automatic
Shaft MaterialSAE 1040/45 Carbon Steel
PaintingRAL 7022 207A (ISO 12944 - C2)
Grounding LugsSingle
Fan Cover materialSteel
Tropicalized PaintingWithout
Fan materialPlastic
Bearing capNo-Without Bearing Cap
Drip CoverWithout
Overload protector (phenolic)Without overload protector
Shaft Locking DeviceWithout
