manufacturer:
Western Enterprises
mpn:
RHP-2-4
weight:
3.41
Product Description
| Manufacturer Part Number | RHP-2-4 |
|---|---|
| GTIN | 698944043377 |
| Family | Western Enterprises RHP Series High Inlet/High Delivery Pressure Regulators |
| Manufacturer | Western Enterprises |
| Manufacturer URL | http://www.westernenterprises.com |
| Hazmat | N |
| Country of Origin | US |
| Features | Dual safety relief valves protect against over-pressurization Self re-seating pressure relief valve Replaceable Delrin thrust bushing for easy adjustment Consistent delivery pressure, minimizes fluctuation over a wide rage of inlet pressures Nickel chrome plated zinc bonnet Comp1 pressure compensated design KEL-F seat assembly Dual inlet filtering system For high pressure cylinders up to 6000PSIG with applications that require high flow rates |
| Body Material | Machined Brass |
| Depth [Nom] | 7 in |
| Flow Cap. [Max] | 3,200 SCFH |
| Gas Type | Compressed Air |
| Gauge Size | 2 in |
| Height [Nom] | 6 in |
| Inlet Connection | CGA 347 |
| Inlet Pressure [Max] | 6,000 psi |
| Length [Nom] | 4 1/2 in |
| Outlet Connection | 1/4 in. NPT(F) |
| Outlet Pressure [Max] | 180 psi |
| Width [Nom] | 7 in |
| Wt. | 3 lb |
