Winters Instruments - PCG9016
Features
- Economical 2” (50mm) gauge with built-in safety features
- Safety blowout back steel case
- ASME B40.100 compliant
- CRN registered
- 5 year warranty
Applications
Beverage dispensing, regulators and tanks. Low pressures are used on the down stream side of a regulator. High pressures are used for measuring cylinder gas or tank pressures
Additional Information
Dial1.5” (40mm), 2” (50mm)
CaseSteel with blowout back, painted black
LensAcrylic
RingSteel, painted black
SocketBrass
Connection1/8” NPT or 1/4” NPT, bottom or back
Bourdon TubeBrass
MovementBrass
PointerAluminum, painted black
Over-Pressure Limit25% of full scale value
Working PressureMaximum 75% of full scale value
Ambient/Process Temperature-40°F to 150°F (-40°C to 65°C)
Accuracy±3-2-3% ANSI/ASME Grade B
Enclosure RatingIP52
Warning This product can expose you to chemicals including lead, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov.
CategoryPressure Gauges
ManufactureWinters Instruments
MpnPCG9016
SubcategoryPcg Compressed Gas Pressure Gauge
